The Behringer CX-3400 V2 Super-X Pro Crossover is a stereo 2-way/3-way and mono 4-way crossover that features limiters, time delay, high-frequency horn equalization, and a mono “Low Sum” output, which is ideal for subwoofer applications.

It can be used to provide high-precision audio frequency separation in multiple speaker setups for sound reinforcement systems.

The Behringer CX-3400 V2 Super-X Pro Crossover V2 provides three modes of operation: 2-way stereo, for left and right lows (woofers) and highs (tweeters); and 3-way stereo, for left and right lows, mids, and highs; and 4-way mono, for lows, low-mids, high-mids, and highs.

The front panel is equipped with an easy-to-read LED matrix, so you can see at a glance which modes have been selected and which controls are active.

Furthermore, the Behringer CX-3400 V2 Super-X Pro Crossover V2 includes a switchable pre-EQ for CD horns that ensures a flat-frequency response before equalization is applied.

This raises the signal gain by 3 dB at 3.5 kHz, increases a 6 dB/octave up to 22.5 kHz, and provides consistent dispersion over the entire CD horn frequency range.

In stereo mode, the Behringer CX-3400 V2 Super-X Pro Crossover V2 can be switched to “mono bass” mode. The LF signals in the left and right channels are summed together and then routed to the channel 1 low-output connector.

This connector can be used to drive your active subwoofers, passive subwoofer power amplifiers, or lighting controllers. The low-sum output is presented in mono since people perceive extremely low-bass frequencies as being omnidirectional.

Features

• Professional stereo 2-way/3-way/mono 4-way crossover featuring state-of-the-art Linkwitz-Riley filters with 24 dB/octave
• Individual limiters on each output for optimal loudspeaker protection
• Adjustable time delay for phase alignment between drivers
• CD horn equalization for constant directivity horn compensation
• Flat summed amplitude response, zero phase difference
• The “Low Sum” function provides mono output for subwoofer operation
• Individual output gain controls for all bands
• Individual output mute switches for easy band adjustment
• Individual phase reverse switches for instant phase correction
• Switchable 25 Hz low-cut filter on each input for low-frequency driver protection
• Servo-balanced and gold-plated XLR connectors for all inputs and outputs
• Ultrahigh precision potentiometers for ultimate accuracy and repeatability
• Illuminated switches for secure operation in dark-stage environments
• Internal switch-mode power supply (100 to 240 VAC) for noise-free audio and low power consumption
